5-axis machining center
Five-axis machining center Due to the complex mutual movement of the cutter and the workpiece according to the control program relative to five coordinates, it allows you to process many different parts of the part without stopping the machine and re-clamping the workpiece, which will significantly save machining time, and in addition, ensure high quality parts.
Name | Value |
---|---|
Limit dimensions of the workpiece to be installed with a clamping device хН, mm | 800*550 |
Table working surface dimensions, mm | 600 |
Maximum weight of the workpiece to be installed with a clamping device, kg | 800 |
X-axis travel, mm | 800 |
Y-axis travel, mm | 800 |
Z-axis travel, mm | 550 |
Positioning accuracy along the X, Y, Z axes, mm | 0,008 |
Three-axis machining center
The vertical machining center can be used for roughing, semi-finishing and finishing return of simple surfaces of workpieces made of steel, non-ferrous metals, titanium and plastics according to a given control program.
The mill is equipped with an electronic software temperature compensation system, a coolant supply system through the tool and spindle nozzles, measuring sensors for measuring the workpiece and tool.
Name | Value |
---|---|
Limit dimensions of the workpiece to be installed with a clamping device LxBхН, mm | 1200*600*500 |
Dimensions of the table working surface LxB, mm | 1300*550 |
Maximum weight of the workpiece to be installed with a clamping device, kg | 1000 |
X-axis travel, mm | 1000 |
Y-axis travel, mm | 550 |
Z-axis travel, mm | 550 |
Positioning accuracy along the X, Y, Z axes, mm | 0,001 |
Accuracy of repeated movements along the X, Y, Z axes, mm | 0,006 |
Turning and milling machining center
The turning and milling machining center provides manufacturing flexibility to machine parts with a variety of configurations.
The transition from simple turning and milling to complex machining with simultaneous operation of several axes allows you to perform all operations on one machine.
Name | Value |
---|---|
Maximum diameter of the item to be installed over the bed, mm | 650 |
The largest diameter of the product being processed milling spindle, mm | 320 650 |
The greatest length of the workpiece, mm | 1500 |
Main spindle bore, mm | 91 |
Positioning accuracy of the main spindle, ang. sec. | ±9 |
Rotation of the milling spindle around its axis (axis B), deg | 240 |
Accuracy of linear positioning of the milling spindle in the X, Y, Z axes | 0,008 |
